Pressure Transducers
The pressure transducer line is a cost-effective solution for high-volume applications. Ruggedly engineered with an all-stainless steel design, this sensor delivers exceptional accuracy and long-term reliability. Its compact size, long-term stability, and ease of installation make it an outstanding choice.
Measurement principle
An externally mounted pressure sensor that measures line/tank pressure to derive fluid level. Depending on the model (SEN-EXT-15P/30P/50P/300P-TD), it offers measuring ranges up to 692 feet of tank height, 0.4% FS accuracy, and a 4–20 mA output. It uses a 1/4 NPT male mounting thread, includes over-pressure protection to 3x, ships with a 15 m (49.2 ft) cable, and runs on a 24 VDC supply.
What it measures
- Pressure (15 / 30 / 50 / 300 PSI models)
- Tank level (up to 692 ft)
Typical use cases
- Hydraulic / mobile hydraulic
- Marine ballast control
- Pneumatic systems
- Food and beverage industry
- Refrigeration systems
- Pumps and compressors
- Energy and water management
- Construction
- Agricultural equipment
- Oil and gas applications
Pairs with the DCon Controller (X-412) via 4–20 mA. Specifications sourced from manufacturer documentation.
